Ironlev’s ferro-magnetic levitation enables contactless, friction-free sliding through the combination of a magnetic slider and an iron rail. Using latest-generation permanent magnets, the system moves heavy loads without electrical power, eliminating sliding friction, wear, and maintenance. By overcoming the limits of wheeled systems, Ironlev sets a new standard in motion technology. A perfect blend of advanced engineering and refined design for smooth, silent, and reliable movement in modern architectural applications.
SYSTEMS FOR WINDOWS
SYSTEMS FOR INTERIORS
Systems for sliding windows and doors
Slim
Magnetic levitation sliding system for minimal panoramic sliding windows and doors. “Slim” Ironlev slider enables to upgrade to magnetic sliding, by perfectly integrating even inside the most compact and minimal profiles.
Load capacity
25 kg
Overall dimensions (mm)
180x31x21,1
Rail section diameter
9mm
Medium
Ironlev magnetic levitation systems for Lift-and-Slide windows and doors. “Medium” Ironlev slider enables standard windows and doors to be upgraded to magnetic sliding, defining a new standard for sliding and drastically reducing the lifting effort.
Load capacity
50 kg
Overall dimensions (mm)
199x45x41,2
Rail section diameter
12mm
Ironlev sash
for Lift-and-Slide system
The Ironlev® sash is designed to allow the integration of “Medium” slider into a Lift-and-Slide system.
The structure material with a high thermal break allows perfect insulation and easy integration into the building structure.
The surface covering is available in multiple materials and finishes, ensuring maximum aesthetic performance.
Sliding systems for interiors
D-Way
The D-way system features Ironlev® levitation technology for smooth, silent movement, enhanced by a coated sliding profile and a special lower guide. Its magnetic soft-closing ensures precision and comfort, while ceiling or wall mounting options provide maximum installation flexibility.
Load capacity
80 kg
Overall section (mm)
53x46
Party
The Party system is an interior partition solution for large sliding doors, combining elegant design and smooth movement. Its coated profile, special guide, and magnetic soft-closing ensure silent, precise operation, with flexible installation options — ceiling, built-in, or wall-mounted, single or double rail.
Max. Load capacity
200 kg
Overall section (mm)
42,4x110
Our Technology
MOVING LIGHTNESS
The window moves along the rail effortlessly and without any sliding friction, overcoming the weight limits of traditional wheeled systems. Pulling force of 2 kg for a 600 kg doorTested with doors up to 1500 kg
MODULARITY
The composition of the sliders allows to determine the number of sliders as a function of the sash weight.
Unlike traditional wheel systems, magnetic levitation distributes the weight of profile and glass evenly among each slider, making it possible to design large openings with minimal frames. Single or double module.
RELIABILITY
The extremely low wear of the elements composing the slider ensures high durability and lifetime. The system is designed and tested for superior performances in terms of corrosion resistance.
N° 100.000 cycles tested
1.000 hours in salt spray environment
SAFETY
The slider is intrinsically safe: the magnetic field is totally confined insider slider section, eliminating external magnetic dispersions. This allows an adoption inside domestic environments by placing the system in the lower node, inside the frame.
μT within standards
EASY INSTALLATION AND ASSEMBLY
The Ironlev system is designed for easy and safe installation. The sliders are assembled by using special accessories that guide the system in the proper position. In addition, the system includes junction and rail fixing elements.
