Ironlev’s ferro-magnetic levitation enables contactless, friction-free sliding through the combination of a magnetic slider and an iron rail. Using latest-generation permanent magnets, the system moves heavy loads without electrical power, eliminating sliding friction, wear, and maintenance. By overcoming the limits of wheeled systems, Ironlev® sets a new standard in motion technology. A perfect blend of advanced engineering and refined design for smooth, silent, and reliable movement in modern architectural applications.
SYSTEMS FOR WINDOWS
SYSTEMS FOR INTERIORS
Systems for sliding windows and doors
Slim®
Magnetic levitation sliding system for minimal panoramic sliding windows and doors. “Slim®” Ironlev slider enables to upgrade to magnetic sliding, by perfectly integrating even inside the most compact and minimal profiles.
Load capacity
25 kg
Overall dimensions (mm)
180x31x21,1
Rail section diameter
9mm
Medium®
Ironlev® magnetic levitation systems for Lift-and-Slide windows and doors. “Medium®” Ironlev® slider enables standard windows and doors to be upgraded to magnetic sliding, defining a new standard for sliding and drastically reducing the lifting effort.
Load capacity
50 kg
Overall dimensions (mm)
199x45x41,2
Rail section diameter
12mm
Ironlev® threshold
for Lift-and-Slide system
The Ironlev® threshold is designed to allow the integration of “Medium®” slider into a Lift-and-Slide system.
The structure material with a high thermal break allows perfect insulation and easy integration into the building structure.
The surface covering is available in multiple materials and finishes, ensuring maximum aesthetic performance.
Sliding systems for interiors
D-Way®
The D-way® system features Ironlev® levitation technology for smooth, silent movement, enhanced by a coated sliding profile and a special lower guide. Its magnetic soft-closing ensures precision and comfort, while ceiling or wall mounting options provide maximum installation flexibility.
Load capacity
80 kg
Overall section (mm)
53x46
Party®
The Party® system is an interior partition solution for large sliding doors, combining elegant design and smooth movement. Its coated profile, special guide, and magnetic soft-closing ensure silent, precise operation, with flexible installation options — ceiling, built-in, or wall-mounted, single or double rail.
Max. Load capacity
200 kg
Overall section (mm)
42,4x110
Our Technology
Ironlev® magnetic levitation allows multiple elements to float without any contact, thanks to the coupling between a magnetic slider and an iron rail. The use of next-generation permanent magnets supports the load without any energy input, eliminating friction and component wear. Movement is fully freed from weight, surpassing the limitations of wheels. Loads and systems glide smoothly, efficiently, and reliably, making Ironlev systems ideal for industrial and automation applications and setting new standards in the industry.
MOVING LIGHTNESS
The window or door moves along the rail effortlessly and smoothly without any sliding friction, overcoming the weight limits of traditional wheeled systems.
2N pulling force is needed to move a 200kg door, while only 2kg pulling force is needed to move a 600kg window.
Ironlev® systems have been tested on doors weighing up to 200kg and on windows weighing up to 1500kg.
MODULARITY
The composition of the sliders determines their number based on the sash or door weight.
Unlike traditional wheeled systems, magnetic levitation distributes the weight of the profile and glass evenly between each slider.
The systems are available in a range of load capacities, each related to the dimensions and weight of the door, making it possible to create wide openings using minimal frames and without design limits.
EASY INSTALLATION AND ASSEMBLY
The Ironlev® system is designed for easy and safe installation. The sliders are assembled by using special accessories that guide the system in the proper position. In addition, the system includes junction and rail fixing elements.
SAFETY
The slider is intrinsically safe: the magnetic field is totally confined insider slider section, eliminating external magnetic dispersions. This allows an adoption inside domestic environments by placing the system in the lower node, inside the frame.
RELIABILITY
The extremely low wear of the elements composing the slider ensures high durability and lifetime.
All Ironlev® systems are tested and certified to 100,000 cycles.
The door system is designed and tested to perform beyond the corrosion resistance requirements, with corrosion resistance certified with 1,000 hours in salt spray environment.
